INFO:
Features:
SAFETY
SPECIFICATIONS:
Features:
SAFETY
- LiFePO4 cells, high consistency, long cycle life and much more safety.
- UN38.3, CE certification for system. UL 1642 for cell
- ABS container, replace VRLA battery perfectly.
- Fast charge performance.
- -20~+55° C widely temperature range.
- Maintenance free.
- Integrated hardware BMS inside.
- Independent protection for charge and discharge.
- Over voltage, low voltage, over temperature and short circuit protection.
SPECIFICATIONS:
- NOMINAL VOLTAGE : 12.8
- NOMINAL CAPACITY : 135 (0.33C)
- NOMINAL ENERGY : 1728
- INTERNAL RESISTANCE : <20
- CYCLE LIFE :
- >4800 @50% DOD
- >3500 @80% DOD
- >3000 @100% DOD
- BMS : OVER CHANGE, OVER DISCHARGE, OVER AND UNDER TEMPERATURE SHORT CIRCUIT PROTECTION, CELL BALANCING.
- PARALLEL SUPPORT : MAX 2 SETS
- SERIES SUPPORT : MAX 4 SETS
- CHARGING VOLTAGE : 14.6
- MAX CHARGING CURRENT : 100
- RECOMMENDED CHARGING CURRENT : 67.5
- END OF DISCHARGE VOLTAGE : 11.2
- MAX DISCHARGING CURRENT : 100
- PULSE DISCHARGE CURRENT : 270A @10S
- CHARGE TEMPERATURE RANGE : 0 - 50C
- DISCHARGE TEMPERATURE RANGE : -20 -55C
- DIMENSION : 330*172*214
- CASE MATERIAL: ABS UL94-HB
- MATERIAL SYSTEMS : LIFEP04
- PROTECTION CLASS : IP65
- TERMINAL : M8
- DESIGNED CALENDAR LIFE : 10 YEARS
