HC SERIES BATTERY SPECS
|
Weight(Kg) |
6.0 Kg |
|
Dimensions(mm) |
170.2×99.1×155×155 mm |
|
Group Size |
BTX20L-BS |
|
Voltage |
12-Volt |
|
CCA |
200 A |
|
CA or MCA |
265 A |
|
HCA |
300 A |
|
PHCA |
535 A |
|
Capacity @ 20hr Rate |
14 AH |
|
Reserve Capacity @ 25 Amps |
20 minutes |
|
Reserve Capacity @ 75 Amps |
- |
|
Internal Resistance(mΩ) |
12.30 mΩ |
|
Short Circuit Current(A) |
1000 A |
|
Case Type |
ABS Plastic - |
|
Terminal Type |
M6 |
|
Terminal Torque |
40～55 in-lbs |
